AA3003 H14 0.5MM Aluminum Sheet For Home Appliances Panel Shell

Detalles del producto

Lugar de origen: PORCELANA

Nombre de la marca: Dingang

Certificación: SGS,ITS,BV

Número de modelo: Dingang - PPAL

Condiciones de pago y envío

Cantidad de orden mínima: 1000 kgs / 1 tonelada métrica

Precio: Negociable

Detalles de empaquetado: Embalaje mareado con paleta de madera

Tiempo de entrega: Dentro de 30-45 días

Condiciones de pago: L/C a la vista o 30% T/T por adelantado como depósito, y un saldo del 70% contra la copia B/L

Capacidad de la fuente: 5000 toneladas / por mes

Consiga el mejor precio
Resaltar:
Nombre:
Hoja de aluminio para paneles de electrodomésticos
Aleación:
3003
Espesor:
0.5 mm
Ancho:
1220 mm
Aleación o no:
Es aleación
Solicitud:
Industria de la construcción
Muestra:
Disponible
Espesor de revestimiento:
PVDF: No menos de 25um PE: no menos de 18um
Reciclable:
Nombre:
Hoja de aluminio para paneles de electrodomésticos
Aleación:
3003
Espesor:
0.5 mm
Ancho:
1220 mm
Aleación o no:
Es aleación
Solicitud:
Industria de la construcción
Muestra:
Disponible
Espesor de revestimiento:
PVDF: No menos de 25um PE: no menos de 18um
Reciclable:
AA3003 H14 0.5MM Aluminum Sheet For Home Appliances Panel Shell


AA3003 H14 0.5MM Aluminum Sheet For Home Appliances Panel Shell


AA3003 H14 0.5mm aluminum sheet is a high-performance material tailored for home appliances panel and shell applications, leveraging the unique properties of the 3000-series aluminum-manganese alloy. Composed primarily of aluminum with manganese as the key alloying element, this sheet in H14 temper (semi-hard) and 0.5mm thickness strikes an exceptional balance between strength, durability, and processability, making it a preferred choice for demanding appliance components.



AA3003 H14 0.5MM Aluminum Sheet For Home Appliances Panel Shell 0



Product Parameters


Product Color Coated Aluminum Sheet/Prepainted Aluminium Coil
Thickness 0.1-1.6mm
Width 30-1600mm
Material 1050, 1060, 1100, 3003, 3004, 3105, 5052, 5005, 5754, 5083, 6061,8081 etc
Temper O, H12, H14, H16, H18, H24, H26, H32, H34, etc
Inner Diameter 405mm,505mm,150mm,etc.
Color RAL, Pantone Color Or As Alient's Demand
Coating thickness PVDF Paint Coating: Not Less Than 25um

PE Paint Coating : Not Less Than 18um
Packing Export Standard Wooden Pallets (Eye To Wall,Eye To Sky)
Payment Terms L/C at sight or 30% T/T in advance as deposit, and 70% balance against the B/L copy.
MOQ 3 Tons Per Specification
Delivery Time Within 30-45 Days
Loading Port Shanghai,Ningbo,Qingdao,Tianjin Port and Etc
Application Aluminum Roofing,ACP,Roller Shutter Window,Roller Shutter Door,Aluminum Ceiling,Aluminum Grilling,Aluminum Downspout System,Home Appliance's Plate, body tank of cold chain truck,high speed rail,aluminum pull ring,food packaging,outer packing case of capacitor,external contour of letter channel



Application Scenarios


  • Washing Machine Outer Shells & Control Panels: Resists moisture, detergent exposure, and minor impacts, ensuring long-term structural integrity.
  • Dishwasher Door Panels & Side Casings: Withstands high humidity and temperature fluctuations in kitchen environments.
  • Air Conditioner Indoor/Outdoor Unit Casings: Combines corrosion resistance (critical for outdoor use) with rigidity to protect internal components.
  • Oven & Microwave Side Panels: Handles moderate heat and daily wear, maintaining shape stability.
  • Refrigerator Door Frames & Trim Panels: Offers a robust base for decorative coatings while enduring frequent opening/closing stress.



AA3003 H14 0.5MM Aluminum Sheet For Home Appliances Panel Shell 1




Advantages

1. Enhanced Strength vs. Pure Aluminum

2. Superior Corrosion Resistance

3. Excellent Formability

4. Optimal Thickness for Structural Support

5. Versatile Surface Compatibility

6. Cost-Effective Performance

7. Weldability & Joining Ease
